Description

ATZ3201F 14inch(16mm)Drill Press

Features:

3/4’(20MM)Max.Chuck Capacity

20-1/4’(356mm)Swing

12 Spindle Speeds

0-45°Table Tilt L&R

With Chuck Guard as CE Requirement

Specification:

Motor(w)   1100/1500

Swing(mm)   515

Max. Drilling capacity(mm)  32

Chuck capacity(mm)            20

Taper                                      MT3

Spindle travel(mm)                120

No. of speed                            12

Speed range 50Hz(rpm)         200-1990

                       60Hz(rpm)       240-2400

Overall height(mm)                1700

Measurement(mm)                 1150x643x310/650x518x313

N.W/G.W.(kg)                         76/79+53/56(2 cartons)

Qty/20’ container                    80
